Call Switch — Nurse Call System (77 0211 00)
The Call Switch (77 0211 00) is a
water-protected nurse call switch designed for reliable use in hospital rooms
and patient care areas. Featuring two red call buttons with reassurance lights,
it ensures patients can easily raise calls while staff benefit from clear, illuminated feedback.
When staff presence is active in the room, the system automatically raises an emergency call.
General Description
The dual-button call switch integrates seamlessly into the
nurse call system, offering reassurance lighting and an intuitive interface.
Its special design not only provides functionality but also makes it visually identifiable
as part of the hospital communication system. Optimized for wall mounting,
it guarantees durability and ease of use.
Specifications
- 2 red call buttons with reassurance light and integrated night location light (red LED)
- Easy plug & play installation
- Clear labeling with simple symbols
- Large touch pads for easy operation
- Standard set to channel 0
- Integrated electronic processor for 3-pole plug-in connection (RAN)
- Switch module with locking hooks for secure fixing
- Support ring for screw fixing on a 1-gang back box
- Attractive, ergonomic design frame
Technical Data
- Colour: Studio white, similar to RAL 9016
- Housing material: Polycarbonate
- Standby current: 7 mA
Order Information
| Order Number | Product Name | Notes |
|---|---|---|
| 77 0211 00 A | Call switch | Dimensions: 91 × 91 × 36 mm |
| 77 0211 00 C | Call switch | Design frame made of white glass — Dimensions: 107 × 107 × 36 mm |
| 77 0211 00 F | Call switch | Dimensions: 80 × 80 × 36 mm |
Necessary Accessories (Order Separately)
| Order Number | Accessory | Notes |
|---|---|---|
| 17 0100 00 | Back box solid wall, 1-gang | See appendix “accessories” |
| 17 5100 00 | Back box partition wall, 1-gang | See appendix “accessories” |
| 70 0807 00 | Connector, 3-pole | See appendix “accessories” |
