Call Switch/WC — Nurse Call System (77 0211 01)
The Call Switch/WC (77 0211 01) is a
water-protected call switch designed for use in hospital bathrooms and WC areas.
Featuring two red call buttons with reassurance lights, it ensures patients can
raise WC calls quickly and safely.
When staff presence is active in the room, the switch automatically raises a
WC emergency call.
General Description
This dual-button WC call switch integrates seamlessly into the
nurse call system. The reassurance lights illuminate brightly when a call is raised,
while the optical design clearly identifies the unit as part of the communication system.
Optimized for wall mounting, the switch is both durable and user-friendly.
Specifications
- 2 red call buttons with reassurance light and integrated night location light (red LED)
- Plug & play installation for easy setup
- Clear labeling with simple symbols
- Large touch pads for safe and quick operation
- Standard set to channel 0
- Integrated electronic processor for 3-pole plug-in connection (RAN)
- Switch module with locking hooks for secure mounting
- Support ring for screw fixing on a 1-gang back box
- Attractive and ergonomic design frame
Technical Data
- Colour: Studio white, similar to RAL 9016
- Housing material: Polycarbonate
- Standby current: 7 mA
Order Information
| Order Number | Product Name | Notes |
|---|---|---|
| 77 0211 01 A | Call switch/WC | Dimensions: 91 × 91 × 36 mm |
| 77 0211 01 C | Call switch/WC | Design frame made of white glass — Dimensions: 107 × 107 × 36 mm |
| 77 0211 01 F | Call switch/WC | Dimensions: 80 × 80 × 36 mm |
Necessary Accessories (Order Separately)
| Order Number | Accessory | Notes |
|---|---|---|
| 17 0100 00 | Back box solid wall, 1-gang | See appendix “accessories” |
| 17 5100 00 | Back box partition wall, 1-gang | See appendix “accessories” |
| 70 0807 00 | Connector, 3-pole | See appendix “accessories” |
